The Kussmaul Super Auto Eject Deluxe Cover with Bar Graph Display combines an Auto Eject protective cover and battery status indicator into one integrated product. Designed for compatible Kussmaul Super Auto Eject systems, the Deluxe Cover provides convenient visual monitoring of vehicle battery status while protecting the shoreline connection on fire apparatus, rescue vehicles, ambulances, and other emergency or specialty vehicles.

The integrated 10-LED bar graph display provides an easy-to-read indication of battery voltage status. The cover features a lid that opens 180 degrees for convenient access to the shoreline connection and includes a premolded rubber gasket for a secure installation. Designed to work with most compatible Kussmaul single-battery chargers, the Deluxe Cover operates from 12 to 30 VDC and includes a 16-foot, 20 AWG, 4-conductor cable.

Available in multiple color options, the Super Auto Eject Deluxe Cover with Bar Graph Display provides an integrated solution for shoreline connection protection and vehicle battery status monitoring.

Features

• Combines a Super Auto Eject cover and battery status indicator in one product
• Integrated 10-LED bar graph battery status display
• Provides convenient visual monitoring of vehicle battery voltage status
• Cover lid opens 180 degrees for easy shoreline connection access
• Compatible with most Kussmaul single-battery chargers
• Includes premolded rubber gasket for secure installation
• Operates from 12 to 30 VDC
• Includes 16-foot, 20 AWG, 4-conductor cable
• Available in blue, black, gray, red, white, and yellow
• Designed for fire apparatus, rescue vehicles, ambulances, and other emergency or specialty vehicle applications
• 3-year warranty

Specifications

• Manufacturer: Kussmaul Electronics
• Product Type: Super Auto Eject Deluxe Cover with Bar Graph Battery Monitor
• Display Type: 10-LED Bar Graph Display
• Monitored Function: Vehicle Battery Voltage Status
• Input Voltage: 12 to 30 VDC
• Maximum Input Current: 50 mA
• High Voltage Indication: Greater Than 14.8 VDC
• Low Voltage Indication: Less Than 12.0 VDC
• Cable Length: 16 Feet
• Cable Type: 20 AWG, 4-Conductor
• Lid Opening: 180 Degrees
• Included Seal: Premolded Rubber Gasket
• Available Colors: Blue, Black, Gray, Red, White, and Yellow
• Operating Temperature Range: -40°F to 120°F
• Charger Compatibility: Most Compatible Kussmaul Single-Battery Chargers
• Warranty: 3 Years
